40A Non-isolated Buck-Boost DC/DC Converter - KUB48xxHB-40A Series

Introduction

40A Non-isolated Buck-Boost DC/DC Converter - KUB48xxHB-40A Series.jpg

With the advancement of robotics and the battery charging industry, the demand for non-isolated high-current power products is increasing rapidly in the market. To cater to the diverse needs of customers, MORNSUN has launched the KUB48xxHB-40A series that delivers a 40A current expanded from a 10A product. This cost-effective product provides customers with more options and addresses issues such as long lead times and high costs.



Advantages

1. High power, high efficiency, wide input/output voltage range

  • Output power up to 1920W, High efficiency up to 96%

  • Wide input voltage range of 14.5-60V, adjustable output voltage range of 15-55V, and adjustable output current of 0-40A. It is designed to be compatible with a variety of input voltages to meet the diverse needs of different applications, ultimately reducing customer management costs and improving efficiency.


2. Parallel connection of up to 4 modules up to 160A

3. Constant current mode for charging applications

4. No-load input current as low as 10 mA

5. Comprehensive functions

  • Ishare-pin can monitor the output current in real-time, ensuring that the product operates under supervision

  • ±sense-pin can compensate for the output line loss and is suitable for long cable devices such as pipe robots

  • Trim-pin for output voltage adjustment

  • Ctrl-pin for remote control


6. Comprehensive protections

  • Input under-voltage, and over-voltage protections; Output over-voltage, short-circuit, output over-current, and over-temperature protections

  • Operating temperature range: -40℃ to 100℃



Applications

KUB48xxHB-40A Series can be widely used in robotics, battery management, communications, DC-DC distributed power supply applications.

KUB48xxHB-40A Series can be widely used in robotics.jpg



Features

  • Ultra-wide input voltage range: 14.5 - 60VDC

  • Output voltage range: 15 - 55VDC

  • Supports a wide range of adjustable regulated outputs

  • High efficiency up to 96%

  • Parallel support

  • Constant current mode

  • Input under-voltage, and over-voltage protections; Output over-voltage, short-circuit, output over-current, and over-temperature protections

  • Operating temperature range: -40℃ to 100℃

  • Industry-standard half-brick package and pin-out


* For detailed information please refer to the related datasheet, product news is for reference only.
