2000W High-power AC/DC Enclosed Power Supply - LMF2000-20Bxx Series

2000W High-power AC/DC Enclosed Power Supply - LMF2000-20Bxx Series.jpg

MORNSUN introduces the latest addition to its range of enclosed switching power supplies - the LMF2000-20Bxx series, which offers power up to 2000W. This product is highly efficient, reliable, and of top-notch quality, and it offers a wide operating temperature range, making it suitable for use in industrial and medical fields.

Advantages

1. Compact size: 290.00×127.00×40.5mm

2. High efficiency up to 92%

3. Wide operating temperature range: -40℃ to +85℃

4. Supports 3+1 parallel redundancy

5. Supports 485 communication, remote shutdown (PS-ON/OFF)

6. High reliability

CE meets CISPR32 EN55032 CLASS B, RE meets CISPR32 EN55032 CLASS A, ESD meets IEC/EN61000-4-2 Contact1±8KV/Air ±15KV
High isolation voltage up to 4000VAC
Comply with CISPR32/EN55032, IEC/EN/UL/BS EN62368, UL60601, GB4943 standards
5 years warranty

Applications

Features

Universal 85 - 277VAC or 120 - 390VDC Input voltage
Wide adjustable output voltage range
Accepts AC or DC input (dual-use of same terminal)
Operating ambient temperature range: -40℃ to +85℃
High efficiency, high reliability
Active PFC
High isolation voltage up to 4000VAC
Supports 3+1 parallel redundancy
Supports 485 communication, remote shutdown (PS-ON/OFF)
Output short circuit, over-current, over-voltage, and over-temperature protections
Operating altitude up to 5000m
Comply with CISPR32/EN55032, IEC/EN/UL/BS EN62368, UL60601, GB4943 standards

* For detailed information please refer to the related datasheet, product news is for reference only.
