600W/1200W, 180-435VDC Wide-Input DC/DC Converter with PMBus function - VRF3D_FB-xxWR3 Series

600W/1200W, 180-435VDC Wide-Input DC/DC Converter with PMBus function - VRF3D_FB-xxWR3 Series.jpg

MORNSUN newly launched two series of 600W and 1200W DC/DC power supplies with a wide input voltage of 180-435VDC to meet the requirement of high-voltage input & high-power applications - VRF3D_FB-600WR3 and VRF3D_FB-1200WR3. This series of products can be widely used in industrial control, data center, communications, automotive, and other related industries.


These standard full-brick power converters feature a high efficiency up to 95%, an ultra-wide operating temperature range of 40℃ to +100℃, high isolation voltage of 3000VAC (enhanced insulation), support for parallel current sharing, and comprehensive multiple protection functions.



Advantages

1.      Excellent temperature derating curve

Temperature performance has a significant impact on product stability. Most switching power supplies have a working temperature range requirement of -40 to +70°C. The VRF3D_FB-1200WR3 series of products have a working temperature range of -40 to +100°C (Base plate) and also deliver excellent performance for full load at 270V and 90°C.

Excellent temperature derating curve.jpg


2.     Supports the PMBus function

The PMBus function of this series enables customers to easily adjust the output voltage, protection threshold, and other parameters, making it more convenient to customize the product application. Additionally, it allows for monitoring of the product's operating status, enabling quick and intelligent response to unexpected faults. For more information, please refer to the datasheet.


3.     High performance with multiple protections

The product has a parallel current-sharing function, which can support up to 4 parallel connections and a total power output of 4800W.

In addition to excellent temperature performance, the product features an isolation voltage of 3000VAC (enhanced insulation), output efficiency of up to 95%, and low ripple and noise. Furthermore, this product includes protections such as input under-voltage, over-voltage protection, output over-voltage, over-current, over-temperature, and short-circuit protection, ensuring the safety of the customer's system or equipment and preventing any unnecessary losses.



Applications

These VRF3D_FB-xxWR3 products can be widely used in industries such as industrial control, communication, and rail transportation, catering to scenarios with high-power and high-reliability requirements, providing high-stability and high-performance quality power supply.

The products should be used in the natural air-cooling environment, if used in a closed environment, please contact our FAE for more details.

VRF3D_FB-xxWR3 products can be used in industrial control.jpg



Features

  • Wide input voltage range: 180-435 VDC

  • High efficiency up to 95%

  • Enhanced insulation, isolation voltage 3000VAC

  • Base plate operating temperature: -40℃ to +100℃

  • Input under-voltage and over-voltage protections, output over-voltage and over-current protections, short circuit protection, and over-temperature protection

  • Support parallel current sharing

  • Support PMBus function

  • International standard full brick

  • Meet the EN62368 certification standard


* For detailed information please refer to the related datasheet, product news is for reference only.
