8W 176-418VAC Ultra-wide input voltage range AC/DC Converter - LS08-15BxxR3P Series

8W 176-418VAC Ultra-wide input voltage range AC/DC Converter - LS08-15BxxR3P Series.jpg

MORNSUN launches the 8W miniaturized AC/DC converter LS08-15BxxR3P series in the SIP package. This series has the advantages of a wide input voltage range of 176 - 418VAC, a small size of 29.82 x 17.20 x 14.05 mm, and an operating temperature range of -40℃ to +85℃. Furthermore, it is a flexible and low-power consumption solution that can be used with the necessary peripheral circuit base on your practical application.


Advantages


Ultra-compact dimension

A small size of 29.82*17.20*14.05mm can be applied in space-limited devices to help customers optimize system layout.



Wide input range of 176 - 418VAC/248 - 591VDC

Full voltage input range without derating for 3-phase power system (380VAC) applications


Wide operating temperature range of -40℃ to +85℃, work well @-20℃ to +55℃ without derating



Outstanding performance

  • Standby power consumption as low as 0.15W, efficiency up to 82%

  • High isolation voltage of 4000VAC

  • Meet EMI CLASS A or CLASS B requirements with the recommended circuit

  • Meet IEC/EN/UL62368 standard

  • 3-year warranty


Applications

Typical application of LS08-15BxxR3P is Charger box.jpg



Features

  • Ultra-wide input voltage range: 176 - 418VAC/ 250 - 590VDC

  • Accepts AC or DC input (dual-use of same terminal)

  • Operating temperature range: -40℃ to +85℃

  • Flexible layout

  • Compact size, high power density, green power

  • Output short circuit, over-current protections

  • Meet IEC/EN/UL62368 standard



* For detailed information please refer to the related datasheet, product news is for reference only.
