5W ultra-compact dual-output AC-DC Converter--LS05-13Dxx in 305RAC Family

MORNSUN AC DC converters LS05-13Dxx with SIP package are part of the 305RAC (reliable under all conditions) family. With an input voltage range of 85 - 305VAC/70-430VDC and compact size, they are ideal for the industrial control system, smart homes, smart building, smart agriculture, household appliance and other fields.

These 5W products have the advantages of a wide operating temperature range of -40℃ to +85℃, low power consumption, and their dimensions is only 29.54*15.7*12mm. Also, they meet IEC/EN61558、IEC/EN60335、UL/IEC/EN62368 standards, and have output short-circuit, over-current and over-voltage protections, which make them suitable for various applications with specific peripheral circuit.

Advantages of LS05-13Dxx series

1) Small-size: 29.54*15.7*12mm

2) Wide input voltage range: 85-305VAC/70-430VDC

These modules comply with the global universal voltage requirements, 110/220/277VAC, and other standard voltages are applicable.

3)  Wide operating temperature, low power consumption

① Operating temperature range: -40℃ to +85℃(Operated at low temperature without derating)

② No-load power consumption as low as 0.15W

4) Stable outputs, multiple protections

① Output short-circuit, over-current, over-voltage protections

② Typical output voltage accuracy of Vo1 is 2%, typical load regulation of Vo1 is 1%

5) Simple peripheral circuit for different applications, good EMC performance

① Satisfy different applications with simple and flexible peripheral circuit

② Satisfy CE(conducted emission) CISPR32/EN55032 CLASS A with a simple peripheral circuit, and the tolerance is more than 6dB

③ Satisfy EFT of IEC/EN61000-4-4 ±4KV with a simple peripheral circuit

Applications of LS05-13Dxx series

It can be widely used in industrial control system, smart homes, smart building, smart agriculture, household appliance and other fields, especially for the high requirements of size and cost.

Features of LS05-13Dxx series

●Small-size: 29.54*15.7*12mm

●High power density, dual-output

●Ultra-wide input voltage range, accepts AC or DC input (dual-use of same terminal)

● input voltage range of 85 - 305VAC/70 - 430VDC, satisfy different requirements of 110VAC/220VAC/240VAC/277VAC

●Operating temperature range: -40℃ to +85℃

●Flexible design for different applications, meet EMI class B without common mode

●No-load power consumption as low as 0.15W

● Output short circuit, over-current, over-voltage protections

● Meets IEC/EN61558, IEC/EN60335, UL/IEC/EN62368 standards (EN pending)
